Min Max Machine is ISO 9001 certified
Min Max Machine Ltd.
 Min Max Machine Ltd.
Pallet: 24.8"
Product X: 36.0"
Product Y: 31.9"
Product Z: 29.5"
Spindle RPM: 4,000 (15K)
Rapid Traverse: 945 in/min
Cutting Feedrate: 472 in/min
Maximum Workpiece: ø43.3" x 38.4"
Maximum Payload: 2,860 lbs
ATC Capacity: 40 (60, 99, 120
Tool to Tool: 3 se40 (60, 99, 120) cs
Chip to Chip: 7 secs
Maximum Tool Length: 17.75"
Maximum Tool Diameter: 5.0"
Maximum Tool Weight: 50 lbs
CATIA Version 5 is an integrated suite of Computer Aided Design (CAD), Computer Aided Engineering (CAE), and Computer Aided Manufacturing (CAM) applications for digital product definition and simulation.
  CATIA Version 5 is the cornerstone of a true integration of people, tools, methodologies and resources within an enterprise. CATIA Version 5 provides advanced 3D Product Lifecycle Management (PLM) solutions for collaborative product development.

Click here to learn more
"The whole system is so intuitive and fun to use that I can almost see it becoming addictive"
Dr Charles V. Clarke, CAD/CAM Consultant
Min Max Machine has recently upgraded inspection equipment with the addition of the Brown & Sharpe Global Status . Single-point probing and high speed scanning capability are combined in the new GLOBAL series of coordinate measuring machines.
HTC400 Specifications
Pallet Size / Number of Pallets 15.7"x15.7" / 2 plts.
Spindle Motor 15 HP
Spindle Torque 51.3 ft./lbs.
Machine Weight 14,767 lbs.
Z-Axis Travel 20.08"
Machine Dimensions 140"x89"x90"
Maximum Tool Diameter / Length 4.52" / 14.96"
Rapid Traverse 1181 IPM
Spindle Center to Table Top 5.9" - 25.98"
Spindle Nose CAT # 40
Spindle Speed up to 10,000 RPM
Table Load Capacity / Indexing 660 lbs. / 15 Deg.
Tool Magazine Capacity 24 Position ATC
Y-Axis Travel 20.08"
X-Axis Travel 22.05"



MA-60HB Specifications
PalletDimensions 24.80 sq. x 630 sq.
X-Y-Z Travels
 39.37 x 31.50 x 31.89
Max. Spindle RPM
 5000/10,000 rpm
ATC Tool Capacity
 40 (Optional 60, 100, 150, 200, 240, 320)

Spindle Motor Power VAC 40/35 (HB model: 10,000 rpm spindle)
VAC 30/26
If you haven't been to Min Max Machine in awhile, maybe it is time to come in and take a tour. Our facility has been expanded 5,000 sq. ft. to facilitate our new state of the art shipping department and our ever growing inventory of parts. Click here to schedule a tour of our facility or call 631-585-4378
