Coming Soon: Feb 2009




See the 4020 video HERE




CATIA Version 5 is an integrated suite of Computer Aided Design (CAD), Computer Aided Engineering (CAE), and Computer Aided Manufacturing (CAM) applications for digital product definition and simulation.

  CATIA Version 5 is the cornerstone of a true integration of people, tools, methodologies and resources within an enterprise. CATIA Version 5 provides advanced 3D Product Lifecycle Management (PLM) solutions for collaborative product development.
"The whole system is so intuitive and fun to use that I can almost see it becoming addictive"
Dr Charles V. Clarke, CAD/CAM Consultant

Min Max Machine has recently upgraded inspection equipment with the addition of the Brown & Sharpe Global Status . Single-point probing and high speed scanning capability are combined in the new GLOBAL series of coordinate measuring machines.


HTC400 Specifications
Pallet Size / Number of Pallets 15.7"x15.7" / 2 plts.
Spindle Motor 15 HP
Spindle Torque 51.3 ft./lbs.
Machine Weight 14,767 lbs.
Z-Axis Travel 20.08"
Machine Dimensions 140"x89"x90"
Maximum Tool Diameter / Length 4.52" / 14.96"
Rapid Traverse 1181 IPM
Spindle Center to Table Top 5.9" - 25.98"
Spindle Nose CAT # 40
Spindle Speed up to 10,000 RPM
Table Load Capacity / Indexing 660 lbs. / 15 Deg.
Tool Magazine Capacity 24 Position ATC
Y-Axis Travel 20.08"
X-Axis Travel 22.05"




MA-60HB Specifications
PalletDimensions 24.80 sq. x 630 sq.
X-Y-Z Travels
39.37 x 31.50 x 31.89
Max. Spindle RPM
5000/10,000 rpm
ATC Tool Capacity
40 (Optional 60, 100, 150, 200, 240, 320)

Spindle Motor Power VAC 40/35 (HB model: 10,000 rpm spindle)
VAC 30/26

If you haven't been to Min Max Machine in awhile, maybe it is time to come in and take a tour. Our facility has been expanded 5,000 sq. ft. to facilitate our new state of the art shipping department and our ever growing inventory of parts.

Click here to schedule a tour of our facility

or call 631-585-4378
